Using coordinate data saved by various applications or devices in your CAD system is not always that simple, as the multiple formatting methods that are employed can make it difficult to perform conversions to DXF.
RapidDXF LT is a helpful application that provides you with a reliable solution to this issue, as it enables you to perform conversions using multiple configurations created for specific types of input data.
Download RapidDXF LT Crack
| Software developer |
DeliCAD
|
| Grade |
3.7
790
3.7
|
| Downloads count | 6021 |
| File size | < 1 MB |
| Systems | Windows 2K, Windows XP, Windows XP 64 bit, Windows Vista, Windows Vista 64 bit, Windows 7, Windows 7 64 bit, Windows 8, Windows 8 64 bit, Windows 10, Windows 10 64 bit |
The application can process files that contain plain text, such as TXT, ASC or CSV documents. You can filter the items that are displayed in the file explorer based on their format, and any number of new extensions can be added.
RapidDXF LT enables you to process multiple files at once, making it a great tool for users who need to convert several sets of coordinates for their CAD projects.
Naturally, coordinate data can be stored in various formats, and the application relies on a user-defined set of instructions in order to extract information from the available fields. These settings can be saved to separate profiles and loaded instantly at any time.
You can specify which type of data is stored in each column, select the right field separator, renumber points and set the default Z value. A helpful preview of the DXF output is also generated.
The program can create DXF files in 2D or 3D, and it is possible to define the number of decimals that should be displayed.
The utility does not rely on other software in order to create DXF files, which means you can use it to convert data even if your CAD system is not installed on the same machine.
Overall, RapidDXF LT Serial is a straightforward and reliable application that enables you to convert coordinate points saved in plain text to the DXF format. It is quite versatile and very easy to use, while also providing you with detailed documentation.
